ROCCIA(瑞卡)
THE MOST ADVANCED 3 ROLLS BENDING MACHINE
3 roll variable axis plate bending machines are used for bending medium to thick plates. They are very precise and easy to use. There are advantages by using this system where the two side rolls move horizontally – left and right, while the top roll moves up and down. When feeding the material into the machine it does not tilt up like it would on a double pinch three roll bender, but stays parallel to the ground allowing easier and safer material handling. When positioning the side rolls at their farthest position, you can increase the rolling capacity byup to 50% more than on a traditional 3 or 4 roll bending machine. Three driving rolls offer full control over the bending process.
Technical Date:
設備型號 | 工件長度(M) | 彎曲厚度(mm) (5×Tp) | 預彎厚度(mm) (5×Tp) | 彎曲厚度(mm) (1.1×Tp) | 預彎厚度(mm) (1.1×Tp) | 上錕直徑 (mm) |
HR3W2006 | 2050 | 6 | 4 | 3.9 | 2.6 | 160 |
HR3W2010 | 2050 | 10 | 8 | 6.5 | 5.2 | 210 |
HR3W2018 | 2050 | 18 | 14 | 11.7 | 9.1 | 260 |
HR3W2025 | 2050 | 25 | 20 | 16.25 | 13 | 300 |
HR3W2040 | 2050 | 40 | 30 | 26 | 19.5 | 380 |
HR3W2050 | 2050 | 50 | 40 | 32.5 | 26 | 430 |
HR3W2080 | 2050 | 80 | 60 | 52 | 39 | 550 |
HR3W2506 | 2600 | 6 | 4 | 3.9 | 2.6 | 190 |
HR3W2510 | 2600 | 10 | 8 | 6.5 | 5.2 | 210 |
HR3W2516 | 2600 | 16 | 13 | 10.4 | 8.45 | 260 |
HR3W2525 | 2600 | 25 | 20 | 16.25 | 13 | 330 |
HR3W2535 | 2600 | 35 | 30 | 22.75 | 19.5 | 370 |
HR3W2540 | 2600 | 40 | 32 | 26 | 19.5 | 400 |
HR3W2550 | 2600 | 50 | 40 | 32.5 | 26 | 450 |
HR3W3006 | 3100 | 6 | 4 | 3.9 | 2.6 | 200 |
HR3W3008 | 3100 | 8 | 6 | 5.2 | 3.9 | 220 |
HR3W3013 | 3100 | 13 | 10 | 8.45 | 6.5 | 280 |
HR3W3020 | 3100 | 20 | 16 | 13 | 10.4 | 340 |
HR3W3032 | 3100 | 32 | 25 | 20.8 | 16.25 | 400 |
HR3W3045 | 3100 | 45 | 35 | 29.25 | 22.75 | 480 |
HR3W3060 | 3100 | 60 | 50 | 39 | 32.5 | 600 |
HR3W3080 | 3100 | 80 | 60 | 52 | 39 | 750 |
HR3W30110 | 3100 | 110 | 80 | 71.5 | 52 | 820 |
HR3W30125 | 3100 | 125 | 100 | 81.25 | 65 | 940 |
HR3W30150 | 3100 | 150 | 120 | 97.5 | 78 | 1000 |
HR3W4006 | 4100 | 6 | 4 | 3.9 | 2.6 | 240 |
HR3W4008 | 4100 | 8 | 6 | 5.2 | 3.9 | 270 |
HR3W4010 | 4100 | 10 | 8 | 6.5 | 5.2 | 320 |
HR3W4012 | 4100 | 12 | 10 | 7.8 | 6.5 | 340 |
HR3W4016 | 4100 | 16 | 14 | 10.4 | 9.1 | 380 |
HR3W4020 | 4100 | 20 | 16 | 13 | 10.4 | 410 |
HR3W4025 | 4100 | 25 | 20 | 16.25 | 13 | 460 |
HR3W4032 | 4100 | 32 | 25 | 20.8 | 16.25 | 510 |
HR3W4040 | 4100 | 40 | 32 | 26 | 20.8 | 580 |
